GUNNAR 601 CMC Technical Support Videos

This is a collection of mechanical support videos that specifically related to GUNNAR 601 & 3001 Computerised Mat Cutters. Please note, some of these videos are advanced and should only be attempted in consultation with a GUNNAR support expert, or by an experienced technician only.

The GUNNAR 601 was a computerized mat cutter designed for high-volume production in framing businesses. Its construction prioritized reliability and efficiency, making it a key tool for professionals in the industry. The machine featured cut-to-the-edge button clamping, which ensured precision during operation.

Equipped with two cutting heads capable of 45° and 90° angle cuts, the GUNNAR 601 allowed users to perform openings and outer cuts simultaneously, streamlining the workflow.

It included automatic blade depth adjustment (DBD) for cutting v-grooves or double mats. The COE-mode functionality enabled consecutive cutting on two surfaces, enhancing productivity.

The GUNNAR 601 was available in two configurations: the 601-XL and the 601-RS second generation, which was slightly faster.

• How to change the blade on a Gunnar 601
• Replacing the 45 Degree Nylon Foot on a Gunnar 601
• Replacing the 90 Degree Nylon Foot on a Gunnar 601
• Replacing the Bevel Head Return Spring on a Gunnar 601
• How to adjust the throttle valve for oval cuts on a Gunnar 601
• How to remove and replace the belt covers on a Gunnar 601
• Checking the Cable Connections on a Gunnar 601 3001 4001
• Checking the Cooling Fans on a Gunnar 601 3001 4001
• Checking the Squareness Alignment of the Y Arm Gantry on the Gunnar 601
• Lubricating the Cutting Head Shafts on a Gunnar 601 3001 4001 Pro
• Lubricating the Roll-On Bearing Guides on a Gunnar 601 3001 4001 Pro
• Replacing the Button Clamp on a Gunnar 601
• Replacing the Start Button & Light Bulb on a Gunnar 601
• Replacing the Stop Button on a Gunnar 601

• Aligning the straight head on a Gunnar 601
• GWS400 Controller Upgrade Video

• How to check and maintain your silent compressor
• How to replace the motor gasket for a Sil Air Silent Compressor
